Kobelco

SK295LC-8

Excavator

Operating Weight
66,800 lb
Max Digging Depth
284 in
Net Power
197.0 hp
All excavators
Kobelco SK295LC-8 Excavator
1 / 5
Image 1 of 5
Image: sinocmp.com

Specifications

38 data points

Operating Specifications

Operating Specifications specifications
Operating Weight66,800 lb
Fuel Capacity122.0 gal
Hydraulic Pump Flow Capacity130.0 gal/min
Hydraulic System Fluid Capacity74.0 gal
Hydraulic System Relief Valve Pressure4,970 psi
Engine Oil Capacity4.8 gal
Cooling System Fluid Capacity6.6 gal
Operating Voltage24 V
Alternator Supplied Amperage70 A

Engine

Engine specifications
Engine ModelF4HE9684B*J1
Displacement410 in³
Power Measured @2,100 rpm
Gross Power204.0 hp
Net Power197.0 hp
AspirationTurbocharged
Torque Measured @1,400 rpm
Max Torque673 lb-ft

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab126 in
Length of Track on Ground158 in
Tail Swing Radius118 in
Width to Outside of Tracks134 in
Removal Counterweight Clearance48 in

Undercarriage

Undercarriage specifications
Ground Pressure7 psi
Track Gauge102 in
Max Travel Speed3.6 mph
Shoe Size32 in
Drawbar Pull57,100 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth284 in
Max Reach Along Ground417 in
Max Loading Height285 in
Max Cutting Height400 in
Shipping Length of Unit402 in
Shipping Height of Unit126 in

Bucket

Bucket specifications
Reference Bucket Capacity1.20 yd³
Maximum Bucket Capacity1.90 yd³
Minimum Bucket Capacity0.90 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed11 rpm
