KobelcoKobelco
SK350LC-10 H&W
Excavator
35 specifications
Kobelco
SK350 LC-10
- Operating Weight
- 83,300 lb
- Max Digging Depth
- 271 in
- Max Digging Depth
- 289 in
- Net Power
- 269.6 hp
1 / 5
Image 1 of 5
Specifications
51 data points
Operating Specifications
| Operating Weight | 83,300 lb |
|---|
Engine
| Engine Model | HINO J08EVV-KSDK |
|---|---|
| Displacement | 469 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 269.6 hp |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 729 lb-ft |
| Bore | 5 in |
| Stroke | 5 in |
| Engine Type | Water-cooled |
| Emission Tier Level | EPA Tier 4 Final |
| Max Digging Reach | 472 in |
Weights
| Operating Weight | 80,689 lb |
|---|
Hydraulic System
| Pump Type | Two variable displacement pumps + One gear pump |
|---|---|
| Boom cylinder | 6 in |
| Bucket cylinder | 6 in |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Overall Length | 445 in |
| Tail Swing Radius | 143 in |
| Track Gauge | 102 in |
| Overall width -Upper Structure | 124 in |
Undercarriage
| Max Travel Speed | 3.7 mph |
|---|
Fluid Capacities
| Fuel Tank | 132.9 gal |
|---|---|
| Hydraulic system | 108.4 gal |
| Engine Oil | 7.6 gal |
| Cooling system | 9.3 gal |
| Diesel exhaust fluid (DEF) tank | 22.0 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 271 in |
|---|---|
| Max Reach Along Ground | 443 in |
| Max Vertical Wall Digging Depth | 230 in |
| Max Digging Reach | 409 in |
| Max Digging Reach on Ground | 409 in |
| Bucket Digging Force - SAE | 45,861 lb |
| Max Digging Height | 406 in |
| Bucket Digging Force - ISO | 51,032 lb |
| Max Dumping Clearance | 278 in |
| Min Dumping Clearance | 122 in |
| Arm Crowd Force - SAE | 44,063 lb |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing radius | 143 in |
Boom/Stick Excavator Option 2
| Max Digging Depth | 289 in |
|---|---|
| Max Vertical Wall Digging Depth | 261 in |
| Max Digging Reach | 434 in |
| Max Digging Reach on Ground | 435 in |
| Max Dumping Clearance | 291 in |
| Min Dumping Clearance | 104 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 332 in |
|---|---|
| Minimum swing radius | 15 in |
| Max Digging Reach on Ground | 466 in |
| Max Dumping Clearance | 298 in |
| Min Dumping Clearance | 61 in |
