KobelcoKobelco
SK350LC-10 H&W
Excavator
35 specifications
Kobelco
SK350 LC-9E
- Operating Weight
- 79,587 lb
- Max Digging Depth
- 268 in
- Max Digging Depth
- 289 in
- Net Power
- 270.0 hp
1 / 5
Image 1 of 5
Specifications
65 data points
Operating Specifications
| Operating Weight | 79,587 lb |
|---|---|
| Fuel Capacity | 153.3 gal |
| Hydraulic System Fluid Capacity | 109.2 gal |
| Hydraulic System Relief Valve Pressure | 4,970 psi |
| Engine Oil Capacity | 7.6 gal |
| Cooling System Fluid Capacity | 7.7 gal |
Engine
| Displacement | 469 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Net Power | 270.0 hp |
| Bore | 5 in |
| Stroke | 5 in |
| Engine Type | Direct injection |
| Max Digging Reach | 472 in |
Hydraulic System
| Pump Type | Two variable displacement pumps and 1 gear pump |
|---|
Dimensions
| Ground Clearance | 236 in |
|---|---|
| Height - Top of Cab | 127 in |
| Overall Length | 37 in |
| Tail Swing Radius | 139 in |
| Gradeability | 70.0 % |
| Ground pressure | 10 psi |
| Overall width -Upper Structure | 119 in |
Undercarriage
| Ground Pressure | 10 psi |
|---|---|
| Track Gauge | 103 in |
| Max Travel Speed | 3.5 mph |
| Number of Shoes per Side | 48 |
| Drawbar Pull | 71,939 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 268 in |
|---|---|
| Max Reach Along Ground | 409 in |
| Max Vertical Wall Digging Depth | 231 in |
| Max Cutting Height | 408 in |
| Minimum swing radius | 177 in |
| Max Digging Reach | 419 in |
| Bucket Digging Force - SAE | 51,032 lb |
| Max Dumping Clearance | 284 in |
| Min Dumping Clearance | 134 in |
| Arm Crowd Force - SAE | 44,063 lb |
| Arm Crowd Force-ISO | 45,861 lb |
| Bucket Digging Force | 45,861 lb |
Bucket
| Reference Bucket Capacity | 2.11 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 289 in |
|---|---|
| Max Vertical Wall Digging Depth | 261 in |
| Max Cutting Height | 409 in |
| Max Reach Along Ground | 435 in |
| Minimum swing radius | 172 in |
| Max Digging Reach | 434 in |
| Bucket Digging Force - SAE | 45,861 lb |
| Bucket Digging Force - ISO | 51,032 lb |
| Max Dumping Clearance | 269 in |
| Min Dumping Clearance | 104 in |
| Horizontal Digging Stroke - Ground | 229 in |
| Arm Crowd Force-SAE | 35,969 lb |
| Arm Crowd Force-ISO | 37,094 lb |
Boom/Stick Excavator Option 3
| Max Digging Depth | 331 in |
|---|---|
| Max Cutting Height | 424 in |
| Max Vertical Wall Digging Depth | 278 in |
| Max Reach Along Ground | 466 in |
| Minimum swing radius | 175 in |
| Bucket Digging Force - SAE | 45,861 lb |
| Bucket Digging Force - ISO | 51,032 lb |
| Max Dumping Clearance | 289 in |
| Min Dumping Clearance | 62 in |
| Arm Crowd Force-SAE | 30,799 lb |
| Horizontal Digging Stroke - Ground | 285 in |
| Arm Crowd Force-ISO | 31,473 lb |
