KobelcoKobelco
SK260LC-9
Excavator
63 specifications
Kobelco
SK850LC
- Operating Weight
- 173,768 lb
- Max Digging Depth
- 324 in
- Max Digging Depth
- 350 in
- Net Power
- 496.2 hp
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 173,768 lb |
|---|---|
| Fuel Capacity | 253.7 gal |
| Hydraulic Pump Flow Capacity | 266.3 gal/min |
| Hydraulic System Fluid Capacity | 226.2 gal |
Engine
| Engine Model | SAA6D140E-5 |
|---|---|
| Displacement | 930 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 496.2 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,350 rpm |
| Max Torque | 1,620 lb-ft |
Dimensions
| Ground Clearance | 33 in |
|---|---|
| Height - Top of Cab | 142 in |
| Length of Track on Ground | 203 in |
| Tail Swing Radius | 176 in |
| Width to Outside of Tracks | 170 in |
| Removal Counterweight Clearance | 62 in |
Undercarriage
| Ground Pressure | 13 psi |
|---|---|
| Track Gauge | 141 in |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 30 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 324 in |
|---|---|
| Max Reach Along Ground | 516 in |
| Max Loading Height | 336 in |
| Max Vertical Wall Digging Depth | 276 in |
| Max Cutting Height | 494 in |
| Shipping Length of Unit | 572 in |
| Shipping Height of Unit | 189 in |
Bucket
| Reference Bucket Capacity | 4.60 yd³ |
|---|---|
| Maximum Bucket Capacity | 7.10 yd³ |
| Minimum Bucket Capacity | 3.70 yd³ |
Swing Mechanism
| Swing Speed | 8 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 350 in |
|---|---|
| Max Vertical Wall Digging Depth | 267 in |
| Max Cutting Height | 478 in |
| Max Loading Height | 329 in |
| Max Reach Along Ground | 534 in |
| Shipping Length of Unit | 572 in |
| Shipping Height of Unit | 189 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 383 in |
|---|---|
| Max Cutting Height | 487 in |
| Max Loading Height | 339 in |
| Max Vertical Wall Digging Depth | 295 in |
| Max Reach Along Ground | 563 in |
| Shipping Length of Unit | 572 in |
| Shipping Height of Unit | 189 in |
