R960 SME Litronic
Excavator
42 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 229,281 lb |
|---|---|
| Fuel Capacity | 359.3 gal |
| Hydraulic Pump Flow Capacity | 419.6 gal/min |
| Hydraulic System Fluid Capacity | 177.0 gal |
| Hydraulic System Relief Valve Pressure | 4,978 psi |
| Engine Oil Capacity | 12.7 gal |
| Cooling System Fluid Capacity | 36.8 gal |
| Swing Drive Fluid Capacity | 5.7 gal |
Engine
| Engine Model | SAA6D170 |
|---|---|
| Displacement | 1,413 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 611.0 hp |
| Aspiration | Turbocharged with aftercooler |
Dimensions
| Ground Clearance | 40 in |
|---|---|
| Height - Top of Cab | 155 in |
| Length of Track on Ground | 197 in |
| Tail Swing Radius | 192 in |
| Width to Outside of Tracks | 181 in |
| Removal Counterweight Clearance | 71 in |
Undercarriage
| Ground Pressure | 19 psi |
|---|---|
| Track Gauge | 154 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 2.0 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 3 |
| Drawbar Pull | 154,324 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 312 in |
|---|---|
| Max Reach Along Ground | 539 in |
| Max Loading Height | 333 in |
| Max Vertical Wall Digging Depth | 198 in |
| Max Cutting Height | 512 in |
| Shipping Length of Unit | 631 in |
| Shipping Height of Unit | 247 in |
Bucket
| Reference Bucket Capacity | 8.59 yd³ |
|---|
Swing Mechanism
| Swing Speed | 6 rpm |
|---|
