Komatsu
Kubota
K008-3
Mini Excavator
40 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 3,638 lb |
|---|---|
| Fuel Capacity | 5.3 gal |
| Hydraulic Pump Flow Capacity | 12.0 gal/min |
| Hydraulic System Fluid Capacity | 6.1 gal |
| Hydraulic System Relief Valve Pressure | 2,988 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 45 A |
| Engine Oil Capacity | 0.8 gal |
| Cooling System Fluid Capacity | 0.9 gal |
Engine
| Engine Model | 3D68E-N3FB |
|---|---|
| Displacement | 48 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 17.0 hp |
| Net Power | 15.3 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
| Torque Measured @ | 1,800 rpm |
Dimensions
| Height - Top of Cab | 89 in |
|---|---|
| Length of Track on Ground | 41 in |
| Tail Swing Radius | 43 in |
| Width to Outside of Tracks | 40 in |
| Removal Counterweight Clearance | 18 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 31 in |
| Number of Track Rollers per Side | 3 |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 9 in |
| Number of Shoes per Side | 31 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 85 in |
|---|---|
| Max Reach Along Ground | 144 in |
| Max Vertical Wall Digging Depth | 62 in |
| Max Loading Height | 100 in |
| Shipping Length of Unit | 148 in |
| Max Cutting Height | 138 in |
| Shipping Height of Unit | 89 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.10 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
