Komatsu
PC290LC-11
- Operating Weight
- 70,702 lb
- Max Digging Depth
- 272 in
- Max Digging Depth
- 284 in
- Net Power
- 197.2 hp
1 / 5
Image 1 of 5
Specifications
57 data points
Operating Specifications
| Operating Weight | 70,702 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 126.6 gal/min |
Engine
| Engine Model | SAA6D107E-3 |
|---|---|
| Displacement | 408 in³ |
| Power Measured @ | 2,050 rpm |
| Gross Power | 213.3 hp |
| Net Power | 197.2 hp |
| Aspiration | Turbocharged |
| Engine Make | Komatsu |
| Stroke | 5 in |
| Bore | 4 in |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 126 in |
| Tail Swing Radius | 120 in |
| Width to Outside of Tracks | 134 in |
| Removal Counterweight Clearance | 48 in |
| Track Gauge | 102 in |
| Track length | 195 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 56 lb |
Fluid Capacities
| Fuel Tank | 105.7 gal |
|---|---|
| Engine Oil | 6.2 gal |
| Swing drive | 2.0 gal |
| Final Drive | 2.2 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 272 in |
|---|---|
| Max Reach Along Ground | 430 in |
| Max Vertical Wall Digging Depth | 228 in |
| Minimum swing radius | 152 in |
| Max Digging Reach | 422 in |
| Max.Dumping Height | 291 in |
| Max Digging Reach on Ground | 411 in |
| Bucket Digging Force - SAE | 39,566 lb |
| Max Digging Height | 406 in |
| Bucket Digging Force - ISO | 44,512 lb |
| Arm Crowd Force - SAE | 29,000 lb |
| Arm Crowd Force-ISO | 30,124 lb |
General Specifications
| Operating Weight lbs (kg) | 72,091 (32,700) — Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 23.4 (7.07) — Starting 2025 Model Year |
| Digging Reach ft. (m) | 35.8 (10.8) — Starting 2025 Model Year |
| Engine hp (kW) | 196 (147) — Starting 2025 Model Year |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 284 in |
|---|---|
| Max Vertical Wall Digging Depth | 230 in |
| Max Reach Along Ground | 422 in |
| Minimum swing radius | 147 in |
| Max Digging Reach | 430 in |
| Max.Dumping Height | 293 in |
| Bucket Digging Force - SAE | 39,566 lb |
| Bucket Digging Force - ISO | 44,512 lb |
| Max. digging height | 408 in |
| Arm Crowd Force-SAE | 27,202 lb |
| Arm Crowd Force-ISO | 28,101 lb |
