ZX350LC-5N
Excavator
20 specifications
1 / 5
Image 1 of 5
Specifications
60 data points
Operating Specifications
| Operating Weight | 126,720 lb |
|---|---|
| Operating Weight w/o Attachment | 144,013 lb |
| Fuel Capacity | 232.5 gal |
| Hydraulic Pump Flow Capacity | 216.7 gal/min |
| Hydraulic System Fluid Capacity | 95.2 gal |
| Hydraulic System Relief Valve Pressure | 4,978 psi |
| Engine Oil Capacity | 9.8 gal |
| Cooling System Fluid Capacity | 15.1 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 3.5 gal |
| Alternator Supplied Amperage | 75 A |
Engine
| Engine Model | SA6D140E-3 |
|---|---|
| Displacement | 930 in³ |
| Power Measured @ | 1,800 rpm |
Hydraulic System
| Pump Type | Variable-capacity piston pumps |
|---|
Dimensions
| Ground Clearance | 31 in |
|---|---|
| Height - Top of Cab | 130 in |
| Length of Track on Ground | 181 in |
| Tail Swing Radius | 150 in |
| Width to Outside of Tracks | 154 in |
| Removal Counterweight Clearance | 54 in |
Transmission
| Transmission Type | Hydrostatic |
|---|---|
| Number of Forward Gears | 2 |
Undercarriage
| Ground Pressure | 14 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.1 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 52 |
| Number of Carrier Rollers per Side | 3 |
| Drawbar Pull | 93,256 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 335 in |
|---|---|
| Max Reach Along Ground | 504 in |
| Max Loading Height | 315 in |
| Max Vertical Wall Digging Depth | 296 in |
| Max Cutting Height | 468 in |
| Shipping Length of Unit | 505 in |
| Shipping Height of Unit | 169 in |
Bucket
| Reference Bucket Capacity | 3.60 yd³ |
|---|---|
| Maximum Bucket Capacity | 4.60 yd³ |
| Minimum Bucket Capacity | 3.20 yd³ |
Swing Mechanism
| Swing Speed | 8 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 278 in |
|---|---|
| Max Vertical Wall Digging Depth | 222 in |
| Max Cutting Height | 439 in |
| Max Loading Height | 284 in |
| Max Reach Along Ground | 445 in |
| Shipping Length of Unit | 467 in |
| Shipping Height of Unit | 181 in |
Boom/Stick Mat. Handler Option 1
| Boom/Stick Option (MAT) 1 | 2-piece front 16.7m 55\' |
|---|---|
| Max Depth | 240 in |
| Max Height | 708 in |
| Max Reach Along Ground | 660 in |
Boom/Stick Mat. Handler Option 2
| Boom/Stick Option (MAT) 2 | 2-piece front 18.3m 60' |
|---|---|
| Max Depth | 276 in |
| Max Height | 768 in |
| Max Reach Along Ground | 732 in |
Track Undercarriage
| Shoe Size | 30 in |
|---|---|
| Length of Track on Ground | 131 in |
| Track Gauge | 161 in |
