Specifications
33 data points
Operating Specifications
| Operating Weight | 7,573 lb |
|---|---|
| Max Speed | 10.0 mph |
| Fuel Capacity | 19.3 gal |
| Hydraulic System Fluid Capacity | 13.3 gal |
| Cooling System Fluid Capacity | 2.2 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Chain Box Fluid Capacity - each side | 8.5 gal |
| Engine Oil Fluid Capacity | 3.4 gal |
| Tire Size | 10-16.5 8PR |
| Operating Speed | 6.3 mph |
Engine
| Engine Model | 4D98E-1FD |
|---|---|
| Displacement | 208 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 70.0 hp |
| Number of Cylinders | 4 |
| Aspiration | natural |
Hydraulic System
| Relief Valve Pressure | 3,046 psi |
|---|---|
| Pump Type | Komatsu closed load sensing system |
| Pump Flow Capacity | 34.4 gal/min |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 83 in |
| Wheelbase | 47 in |
| Width Over Tires | 69 in |
| Reach at Max Lift and Dump | 27 in |
| Length with Bucket | 145 in |
| Clearance at Max Lift and Dump | 90 in |
| Turning Radius from Center - inc bucket | 89 in |
| Turning Radius from Center - machine rear | 65 in |
Loader
| Bucket Capacity | 0.71 yd³ |
|---|---|
| Tipping Angle | 3,999 ° |
| Breakout Force | 4,277 psi |
| Operating Load Rating | 2,000 lb |
