456ZX High Lift
Wheel Loader
42 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 42,593 lb |
|---|---|
| Fuel Capacity | 99.1 gal |
| Tire Size | 23.5-25 20PR (L-3) |
| Static Tipping Weight | 32,849 lb |
| Turning Radius | 289 in |
| Cooling System Fluid Capacity | 16.2 gal |
Engine
| Engine Model | -Cummins NT855 |
|---|---|
| Displacement | 855 in³ |
| Gross Power | 235.0 hp |
Hydraulic System
| Raise Time | 6.8 s |
|---|---|
| Lower Time | 3.5 s |
| Dump Time | 1.9 s |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 142 in |
| Wheelbase | 132 in |
| Width Over Tires | 114 in |
| Reach at Max Lift and Dump | 48 in |
| Length with Bucket on Ground | 323 in |
| Hinge Pin - Max Height | 165 in |
Transmission
| Max Speed - Forward | 20.7 mph |
|---|---|
| Max Speed - Reverse | 20.7 mph |
| Transmission Type | full powershift countershaft |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 4.60 yd³ |
|---|---|
| Dump Clearance at Max Raise | 121 in |
| Breakout Force | 45,810 lb |
| Bucket Width | 121 in |
