Komatsu
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 14,176 lb |
|---|---|
| Fuel Capacity | 31.0 gal |
| Tire Size | 16.9-24-10PR (L2) |
| Static Tipping Weight | 10,869 lb |
| Turning Radius | 194 in |
| Cooling System Fluid Capacity | 8.5 gal |
Engine
| Engine Model | 4D105 |
|---|---|
| Displacement | 264 in³ |
| Gross Power | 72.0 hp |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 114 in |
| Wheelbase | 97 in |
| Width Over Tires | 88 in |
| Reach at Max Lift and Dump | 39 in |
| Length with Bucket on Ground | 214 in |
| Hinge Pin - Max Height | 133 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 21.2 mph |
| Transmission Type | Torqflow countershaft soft shift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.60 yd³ |
|---|---|
| Dump Clearance at Max Raise | 106 in |
| Breakout Force | 13,070 lb |
| Bucket Width | 95 in |
Comparable machines
Other wheel loaders in a similar weight class.
