Komatsu
Caterpillar
980G
Wheel Loader
55 specifications
Komatsu
WA450-3
- Operating Weight
- 108,798 lb
- Bucket Capacity - heaped
- 5.49 yd³
- Gross Power
- 290.0 hp
- Net Power
- 264.0 hp
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 108,798 lb |
|---|---|
| Fuel Capacity | 100.7 gal |
| Tire Size | 26.5-25-20PR(L3) |
| Hydraulic System Fluid Capacity | 54.5 gal |
| Operating Voltage | 24 V |
| Turning Radius | 270 in |
| Engine Oil Fluid Capacity | 9.0 gal |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 17.2 gal |
| Cooling System Fluid Capacity | 14.6 gal |
| Transmission Fluid Capacity | 17.2 gal |
Engine
| Engine Model | Cummins M11 |
|---|---|
| Displacement | 664 in³ |
| Power Measured @ | 2,140 rpm |
| Gross Power | 290.0 hp |
| Net Power | 264.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Water-cooled |
| Stroke | 6 in |
| Bore | 5 in |
| Engine Type | Direct-Injection |
Hydraulic System
| Pump Type | HYDRAULIC |
|---|---|
| Relief Valve Pressure | 3,000 psi |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 141 in |
| Wheelbase | 134 in |
| Width Over Tires | 119 in |
| Reach at Max Lift and Dump | 47 in |
| Length with Bucket on Ground | 331 in |
| Hinge Pin - Max Height | 167 in |
Transmission
| Max Speed - Forward | 21.1 mph |
|---|---|
| Max Speed - Reverse | 22.4 mph |
| Transmission Type | Full power shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.49 yd³ |
|---|---|
| Bucket Capacity - struck | 4.80 yd³ |
| Dump Clearance at Max Raise | 121 in |
| Breakout Force | 42,730 lb |
| Bucket Width | 126 in |
| Digging depth | 13 in |
