Komatsu
WA600-3
- Operating Weight
- 101,777 lb
- Bucket Capacity - heaped
- 8.00 yd³
- Gross Power
- 522.0 hp
- Net Power
- 458.0 hp
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 101,777 lb |
|---|---|
| Fuel Capacity | 177.0 gal |
| Tire Size | 35/65-33 24PR (L4) |
| Hydraulic System Fluid Capacity | 56.8 gal |
| Static Tipping Weight | 73,392 lb |
| Operating Voltage | 24 V |
| Turning Radius | 335 in |
| Engine Oil Fluid Capacity | 12.5 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 75 A |
| Front Axle/Diff Fluid Capacity | 32.8 gal |
| Rear Axle/Diff Fluid Capacity | 32.8 gal |
| Cooling System Fluid Capacity | 42.3 gal |
| Transmission Fluid Capacity | 29.1 gal |
Engine
| Engine Model | SAA6D170E-3 |
|---|---|
| Displacement | 1,413 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 522.0 hp |
| Net Power | 458.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 130.0 gal/min |
|---|---|
| Raise Time | 8.2 s |
| Lower Time | 4.3 s |
| Dump Time | 2.4 s |
| Relief Valve Setting | 3,000 psi |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 168 in |
| Wheelbase | 162 in |
| Width Over Tires | 142 in |
| Reach at Max Lift and Dump | 79 in |
| Length with Bucket on Ground | 366 in |
| Hinge Pin - Max Height | 204 in |
Transmission
| Max Speed - Forward | 22.7 mph |
|---|---|
| Max Speed - Reverse | 24.9 mph |
| Transmission Type | automatic full powershift planetary gear |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 8.00 yd³ |
|---|---|
| Bucket Capacity - struck | 6.70 yd³ |
| Dump Clearance at Max Raise | 132 in |
| Breakout Force | 82,898 lb |
| Bucket Width | 145 in |
