Komatsu
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 12,566 lb |
|---|---|
| Fuel Capacity | 16.7 gal |
| Tire Size | 17.5/65 20-10PR |
| Turning Radius | 186 in |
Engine
| Engine Model | 4D95L |
|---|---|
| Displacement | 199 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 55.3 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 110 in |
| Wheelbase | 97 in |
| Width Over Tires | 76 in |
| Reach at Max Lift and Dump | 52 in |
| Length with Bucket on Ground | 200 in |
| Hinge Pin - Max Height | 142 in |
Transmission
| Max Speed - Forward | 18.1 mph |
|---|---|
| Max Speed - Reverse | 18.7 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.10 yd³ |
|---|---|
| Dump Clearance at Max Raise | 115 in |
| Bucket Width | 78 in |
