Kubota

KX057-4A1

Mini Excavator

Operating Weight
26,268 lb
Max Digging Depth
152 in
Gross Power
47.6 hp
Net Power
45.4 hp
All mini excavators
Kubota KX057-4A1 Mini Excavator
1 / 5
Image 1 of 5
Image: rent1usa.com

Specifications

33 data points

Operating Specifications

Operating Specifications specifications
Operating Weight26,268 lb
Operating weight Cabin26,709 lb
Fuel Capacity18.0 gal
Hydraulic Pump Flow Capacity11.9 gal/min
Hydraulic System Fluid Capacity20.9 gal
Travel speed, high range3.1 mph
Travel speed, low range1.8 mph
Auxiliary hydraulic flow19.9 gal/min
Auxiliary fuel tank9.8 gal

Engine

Engine specifications
Engine ModelKX057-4
Displacement9,739 in³
Power Measured @2,200 rpm
Gross Power47.6 hp
Net Power45.4 hp
Number of Cylinders4
Model NameKX057-4(1)

Dimensions

Dimensions specifications
Ground Clearance13 in
Overall Length219 in
Overall Width77 in

Undercarriage

Undercarriage specifications
Ground Pressure5 psi
Shoe Size16 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth152 in
Max Vertical Wall Digging Depth69 in
Max.Dumping Height166 in
Max Digging Height227 in
Mximum dig radius246 in

Boom

Boom specifications
Boom swing left70 °
Boom swing right55 °

Swing Mechanism

Swing Mechanism specifications
Swing Speed9 rpm

Blades

Blades specifications
Blade Width78 in
Blade Lift Height17 in
Maximum Drop below ground17 in
Overall Height101 in
