Liebherr
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight | 37,900 lb |
|---|---|
| Fuel Capacity | 66.0 gal |
| Hydraulic Pump Flow Capacity | 66.0 gal/min |
| Hydraulic System Fluid Capacity | 79.5 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Hydraulic Pump Type | Liebherr axial piston variable displacement pump |
Engine
| Engine Model | Liebherr D924 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 141.0 hp |
| Number of Cylinders | 4 |
| Bore | 4 in |
| Stroke | 5 in |
| Engine Type | 4 cylinder in-line |
| Cooling system | Water-cooled |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 101 in |
| Overall Width | 99 in |
| Tail Swing Radius | 85 in |
Transmission
| Max Travel Speed | 18.6 mph |
|---|
Bucket
| Maximum Bucket Capacity | 1.20 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 39,827 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 194 in |
|---|---|
| Max Reach Along Ground | 326 in |
| Shipping Length of Unit | 325 in |
| Shipping Height of Unit | 115 in |
| Max Dumping Height | 271 in |
| Max breakout force | 19,180 lb |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 205 in |
|---|---|
| Max Reach Along Ground | 323 in |
| Shipping Height of Unit | 115 in |
| Shipping Length of Unit | 313 in |
| Max Dumping Height | 241 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 205 in |
|---|---|
| Max Reach Along Ground | 326 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 325 in |
Electrical System
| Batteries | 2 x 135 Ah/12 volts |
|---|---|
| Alternator | — |
| Voltage | 24 V |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 189 in |
|---|---|
| Max Reach Along Ground | 308 in |
| Shipping Height of Unit | 121 in |
| Shipping Length of Unit | 301 in |
