Liebherr
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 12,081 lb |
|---|---|
| Static Tipping Weight | 8,431 lb |
| Turning Radius | 76 in |
Engine
| Engine Model | D404T |
|---|---|
| Displacement | 167 in³ |
| Power Measured @ | 2,800 rpm |
| Net Power | 61.7 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 107 in |
| Wheelbase | 85 in |
| Width Over Tires | 77 in |
| Reach at Max Lift and Dump | 32 in |
| Length with Bucket on Ground | 205 in |
Transmission
| Max Speed - Forward | 12.5 mph |
|---|---|
| Max Speed - Reverse | 12.5 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.40 yd³ |
|---|---|
| Dump Clearance at Max Raise | 100 in |
| Bucket Width | 83 in |
