Liebherr
John Deere
290D
Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 33,731 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 111.0 gal/min |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
Engine
| Displacement | 183 in³ |
|---|---|
| Power Measured @ | 2,300 rpm |
| Net Power | 83.2 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Length of Track on Ground | 122 in |
| Tail Swing Radius | 79 in |
| Width to Outside of Tracks | 100 in |
Undercarriage
| Max Travel Speed | 2.8 mph |
|---|---|
| Shoe Size | 20 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 217 in |
|---|---|
| Max Reach Along Ground | 337 in |
| Max Loading Height | 278 in |
| Max Vertical Wall Digging Depth | 198 in |
| Shipping Length of Unit | 307 in |
| Shipping Height of Unit | 117 in |
Bucket
| Reference Bucket Capacity | 0.80 yd³ |
|---|
