Liebherr

R950 DEMOLITION Litronic

Excavator

Operating Weight
163,363 lb
Max Digging Depth
221 in
Max Digging Depth
240 in
All excavators
Liebherr R950 DEMOLITION Litronic Excavator
1 / 5
Image 1 of 5
Image: truck1.eu

Specifications

41 data points

Operating Specifications

Operating Specifications specifications
Operating Weight163,363 lb

Engine

Engine specifications
Engine ModelD944 A7
Displacement486 in³
Power Measured @1,800 rpm
Torque Measured @1,100 rpm
Max Torque1,070 lb-ft
Stroke6 in
Bore5 in
Emission Tier LevelTier 4 Final
Air cleanerDry-type
Cooling systemwater-cooled
Horsepower, Net-ISO 9249272.0 hp
Horsepower, Net-SAE J1349268.0 hp

Hydraulic System

Hydraulic System specifications
system pressure5,511 psi

Dimensions

Dimensions specifications
Ground Clearance15 in
Height - Top of Cab119 in
Wheelbase197 in
Undercarriage Width165 in

Undercarriage

Undercarriage specifications
Number of Track Rollers per Side11
Max Travel Speed1.9 mph
Number of Carrier Rollers per Side3
Drawbar Pull102,738 lb

Fluid Capacities

Fluid Capacities specifications
Fuel Tank203.0 gal
Hydraulic system304.0 gal

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth221 in
Max.Dumping Height396 in
Maximum Reach at Ground Level458 in
Max. teeth height6,408 in
Breakout force - ISO53,350 lb
Digging force - ISO51,370 lb

Bucket

Bucket specifications
Maximum Bucket Capacity3.30 yd³

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth240 in
Max.Dumping Height414 in
Max. teeth height551 in
Maximum Reach at Ground Level41 in
Breakout force-ISO53,350 lb
Digging force - ISO45,200 lb

Electrical System

Electrical System specifications
Batteries2 x 180 Ah / 12 V volts
Alternator—
Voltage24 V
Engine idlingSensor controlled
