Liebherr
Kobelco
SK260LC-9
Excavator
63 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 177,030 lb |
|---|
Engine
| Engine Model | D9508 A7 SCR |
|---|---|
| Displacement | 986 in³ |
| Power Measured @ | 1,800 rpm |
| Torque Measured @ | 1,100 rpm |
| Max Torque | 2,028 lb-ft |
| Stroke | 6 in |
| Bore | 5 in |
| Emission Tier Level | Tier 4 Final |
| Air cleaner | Dry-type |
| Cooling system | water-cooled |
| Horsepower, Net-ISO 9249 | 449.0 hp |
| Horsepower, Net-SAE J1349 | 443.0 hp |
Hydraulic System
| system pressure | 5,076 psi |
|---|
Dimensions
| Ground Clearance | 30 in |
|---|---|
| Height - Top of Cab | 143 in |
| Wheelbase | 190 in |
| Undercarriage Width | 165 in |
Undercarriage
| Number of Track Rollers per Side | 8 |
|---|---|
| Max Travel Speed | 2.2 mph |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 127,692 lb |
Fluid Capacities
| Fuel Tank | 301.0 gal |
|---|---|
| Hydraulic system | 196.0 gal |
| Urea tank | 48.0 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 284 in |
|---|---|
| Max.Dumping Height | 311 in |
| Maximum Reach at Ground Level | 459 in |
| Max. teeth height | 459 in |
| Breakout force - ISO | 88,180 lb |
| Digging force - ISO | 80,470 lb |
Bucket
| Maximum Bucket Capacity | 6.61 yd³ |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 291 in |
|---|---|
| Max.Dumping Height | 318 in |
| Max. teeth height | 458 in |
| Maximum Reach at Ground Level | 40 in |
| Breakout force-ISO | 88,180 lb |
| Digging force - ISO | 73,630 lb |
Electrical System
| Batteries | 2 x 180 Ah / 12 V volts |
|---|---|
| Alternator | — |
| Voltage | 24 V |
| Engine idling | Sensor controlled |
