Link Belt
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 83,304 lb |
|---|---|
| Fuel Capacity | 153.3 gal |
| Hydraulic Pump Flow Capacity | 142.0 gal/min |
| Hydraulic System Fluid Capacity | 84.6 gal |
| Hydraulic System Relief Valve Pressure | 4,620 psi |
| Engine Oil Capacity | 9.0 gal |
| Cooling System Fluid Capacity | 15.1 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 3.4 gal |
| Alternator Supplied Amperage | 70 A |
Engine
| Engine Model | MII-C265 |
|---|---|
| Displacement | 661 in³ |
| Power Measured @ | 1,700 rpm |
| Net Power | 240.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 900 lb-ft |
Dimensions
| Ground Clearance | 29 in |
|---|---|
| Height - Top of Cab | 132 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 132 in |
| Width to Outside of Tracks | 144 in |
| Removal Counterweight Clearance | 57 in |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 117 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.1 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 283 in |
|---|---|
| Max Reach Along Ground | 431 in |
| Max Loading Height | 341 in |
| Max Vertical Wall Digging Depth | 241 in |
| Max Cutting Height | 414 in |
| Shipping Length of Unit | 431 in |
| Shipping Height of Unit | 134 in |
Bucket
| Reference Bucket Capacity | 1.50 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.80 yd³ |
| Minimum Bucket Capacity | 1.20 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
