Mec
Haulotte
COMPACT 2032E
Aerial Lift
26 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Engine
| System Voltage | 24 V |
|---|---|
| Battery Amp Hours | 220 |
| Number of Batteries | 4 |
| Charger Amps | 25 |
Dimensions
| Ground Clearance | 3 in |
|---|---|
| Wheelbase | 50 in |
| Overall Length | 6 in |
| Overall Width | 32 in |
| Turning Radius | 72 in |
| Height w/ Rails | 79 in |
Performance
| Operating Weight | 3,031 lb |
|---|---|
| Max Speed | 3.0 mph |
| Tire Size | 14x4.5 |
| Hydraulic System Fluid Capacity | 3.0 gal |
| Tire Fill/Type | Solid non-marking |
Platform
| Max Platform Height | 228 in |
|---|---|
| Max Platform Weight Capacity | 500 lb |
| Platform Inner Length | 66 in |
| Max Working Height | 307 in |
| Deck Extension | 36 in |
| Height of Rails | 41 in |
