Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Fuel Capacity | 84.6 gal |
|---|---|
| Tire Size | 23.5R25 |
| Engine Oil Capacity | 7.2 gal |
| Cooling System Fluid Capacity | 9.6 gal |
| Hydraulic System Fluid Capacity | 36.5 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 A |
| Transmission Fluid Capacity | 15.1 gal |
Engine
| Engine Model | DC 9 |
|---|---|
| Displacement | 549 in³ |
| Gross Power | 313.8 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Max Torque | 1,069 lb-ft |
| Make | Scania |
Weights
| Operating Weight | 100,310 lb |
|---|---|
| Total Empty | 48,502 lb |
| Front Axle - empty | 24,141 lb |
| Total Loaded | 100,310 lb |
| Rear Axle - empty | 24,361 lb |
| Front Axle - loaded | 33,510 lb |
| Rear Axle - loaded | 66,800 lb |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Overall Length | 371 in |
| Overall Width | 109 in |
| Overall Height | 141 in |
| Dump Height | 211 in |
| Dump Ground Clearance | 25 in |
Transmission
| Max Speed | 31.7 mph |
|---|---|
| Transmission Type | ZF 6 WG 260 Dash 4 electronically-controlled automatic |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Drive System
| Drive Config | 6X6 |
|---|
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 51,809 lb |
|---|---|
| Raise Time | 11.0 s |
| Lower Time | 10.0 s |
| Capacity - Heaped | 18.49 yd³ |
| Capacity - Struck | 15.00 yd³ |
