Mustang
Case
21D
Wheel Loader
43 specifications
Mustang
ML68
- Operating Weight
- 12,015 lb
- Bucket Capacity - heaped
- 2.39 yd³
- Gross Power
- 79.0 hp
- Net Power
- 75.0 hp
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 12,015 lb |
|---|---|
| Fuel Capacity | 21.1 gal |
| Tire Size | 16 / 70- 20 |
| Hydraulic System Fluid Capacity | 22.5 gal |
| Static Tipping Weight | 8,730 lb |
| Turning Radius | 157 in |
| Rear Axle Oscillation | 40 ° |
Engine
| Engine Model | BF4M2011 |
|---|---|
| Displacement | 190 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 79.0 hp |
| Net Power | 75.0 hp |
| Number of Cylinders | 4 |
| Torque Rise | 50.0 % |
Hydraulic System
| Pump Flow Capacity | 22.2 gal/min |
|---|---|
| Relief Valve Setting | 3,191 psi |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 108 in |
| Wheelbase | 81 in |
| Width Over Tires | 72 in |
| Reach at Max Lift and Dump | 25 in |
| Length with Bucket on Ground | 221 in |
| Hinge Pin - Max Height | 134 in |
Transmission
| Max Speed - Forward | 12.4 mph |
|---|---|
| Max Speed - Reverse | 12.4 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 1 |
| Number of Reverse Gears | 1 |
Bucket
| Bucket Capacity - heaped | 2.39 yd³ |
|---|---|
| Bucket Capacity - struck | 1.40 yd³ |
| Dump Clearance at Max Raise | 106 in |
| Breakout Force | 9,217 lb |
| Bucket Width | 85 in |
