Komatsu
PC03-2F
Mini Excavator
27 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 1,676 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 5.4 gal/min |
Engine
| Displacement | 44 in³ |
|---|---|
| Power Measured @ | 2,000 rpm |
| Net Power | 7.4 hp |
| Number of Cylinders | 3 |
Dimensions
| Length of Track on Ground | 39 in |
|---|---|
| Tail Swing Radius | 37 in |
| Width to Outside of Tracks | 36 in |
Undercarriage
| Max Travel Speed | 1.3 mph |
|---|---|
| Shoe Size | 7 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 61 in |
|---|---|
| Max Reach Along Ground | 113 in |
| Max Vertical Wall Digging Depth | 46 in |
| Max Loading Height | 79 in |
| Shipping Length of Unit | 115 in |
| Shipping Height of Unit | 81 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|
