New Holland
LW50.B
- Operating Weight
- 10,038 lb
- Bucket Capacity - heaped
- 0.99 yd³
- Gross Power
- 57.0 hp
- Net Power
- 53.0 hp
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 10,038 lb |
|---|---|
| Fuel Capacity | 23.5 gal |
| Hydraulic System Fluid Capacity | 15.5 gal |
| Static Tipping Weight | 7,634 lb |
| Operating Voltage | 12 V |
| Turning Radius | 148 in |
| Engine Oil Fluid Capacity | 2.0 gal |
| Alternator Supplied Amperage | 65 A |
| Front Axle/Diff Fluid Capacity | 1.2 gal |
| Rear Axle/Diff Fluid Capacity | 1.5 gal |
| Cooling System Fluid Capacity | 3.0 gal |
Engine
| Engine Model | 704.3 |
|---|---|
| Displacement | 183 in³ |
| Gross Power | 57.0 hp |
| Net Power | 53.0 hp |
| Aspiration | Natural |
Hydraulic System
| Pump Flow Capacity | 14.0 gal/min |
|---|---|
| Raise Time | 6.0 s |
| Lower Time | 3.0 s |
| Dump Time | 1.0 s |
| Relief Valve Setting | 3,335 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 106 in |
| Wheelbase | 84 in |
| Width Over Tires | 72 in |
| Reach at Max Lift and Dump | 33 in |
| Length with Bucket on Ground | 202 in |
| Hinge Pin - Max Height | 121 in |
Transmission
| Max Speed - Forward | 12.4 mph |
|---|---|
| Max Speed - Reverse | 12.4 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 0.99 yd³ |
|---|---|
| Dump Clearance at Max Raise | 94 in |
| Breakout Force | 12,050 lb |
