New Holland
John Deere
290D
Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight | 33,808 lb |
|---|---|
| Fuel Capacity | 55.5 gal |
| Hydraulic Pump Flow Capacity | 87.2 gal/min |
| Hydraulic System Fluid Capacity | 29.1 gal |
| Hydraulic System Relief Valve Pressure | 5,004 psi |
| Engine Oil Capacity | 3.5 gal |
| Cooling System Fluid Capacity | 6.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Hydraulic Pump Type | 3 Variable Displacement Axial Piston |
| Tire Size | 10.00-20 |
Engine
| Engine Model | CNH - F4BE0484E |
|---|---|
| Displacement | 238 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 111.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharger and charge air cooling |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 119 in |
| Wheelbase | 101 in |
| Overall Width | 8 in |
| Tail Swing Radius | 70 in |
| Upper Structure Clearance | 49 in |
| Overall Width - Outriggers Down | 154 in |
Transmission
| Max Travel Speed | 12.5 mph |
|---|---|
| Drawbar Pull | 20,458 lb |
Bucket
| Reference Bucket Capacity | 0.60 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.90 yd³ |
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 28,027 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 189 in |
|---|---|
| Max Cutting Height | 364 in |
| Max Reach Along Ground | 320 in |
| Max Loading Height | 268 in |
| Shipping Length of Unit | 323 in |
| Shipping Height of Unit | 119 in |
| Max Vertical Wall Dig Depth | 122 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 199 in |
|---|---|
| Max Cutting Height | 369 in |
| Max Reach Along Ground | 330 in |
| Max Loading Height | 272 in |
| Shipping Height of Unit | 119 in |
| Shipping Length of Unit | 323 in |
| Max Vertical Wall Dig Depth | 139 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 211 in |
|---|---|
| Max Cutting Height | 377 in |
| Max Reach Along Ground | 341 in |
| Max Loading Height | 281 in |
| Shipping Height of Unit | 121 in |
| Shipping Length of Unit | 319 in |
| Max Vertical Wall Dig Depth | 150 in |
