New Holland
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Operating Weight | 11,685 lb |
|---|---|
| Fuel Capacity | 26.5 gal |
| Tire Size | 14.5-20 |
| Static Tipping Weight | 9,414 lb |
Engine
| Net Power | 45.0 hp |
|---|
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 109 in |
| Wheelbase | 89 in |
| Reach at Max Lift and Dump | 126 in |
| Length with Bucket on Ground | 211 in |
Transmission
| Transmission Type | hydrostatic |
|---|
Bucket
| Bucket Capacity - heaped | 1.20 yd³ |
|---|---|
| Dump Clearance at Max Raise | 100 in |
| Bucket Width | 81 in |
