Ponsse
Caterpillar
554
Forwarder
33 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight - 8wd | 35,054 lb |
|---|---|
| Operating Weight - 6wd | 31,196 lb |
| Fuel Capacity | 39.7 gal |
| Hydraulic System Fluid Capacity | 52.9 gal |
| Alternator Supplied Amperage | 160 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 6wd | 600-26.5/600-26.5 |
Engine
| Engine Model | OM906LA |
|---|---|
| Torque Measured @ | 1,500 rpm |
| Power | 275.0 hp |
| Torque | 811 lb-ft |
Hydraulic System
| Pump Type | Load-sensing system |
|---|---|
| Relief Valve Pressure | 3,408 psi |
Dimensions
| Ground Clearance | 28 in |
|---|---|
| Width Over Tires | 118 in |
| Length | 444 in |
Transmission
| Max Speed | 17.4 mph |
|---|---|
| Transmission Type | Hydrostatic-mechanical |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bunk
| Load Area | 23.20 yd³ |
|---|---|
| Load Weight - 6wd | 30,865 lb |
Crane
| Max Reach | 359 in |
|---|---|
| Gross Lift Torque | 70,068 lb-ft |
| Crane Type | Ponsse K70 |
