Ponsse
Caterpillar
570
Processor
18 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 35,274 lb |
|---|---|
| Max Speed | 17.4 mph |
| Fuel Capacity | 105.7 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 160 A |
| Hydraulic System Fluid Capacity | 92.5 gal |
| Transmission Type | Hydrostatic-mechanical power |
Engine
| Engine Model | OM906LA |
|---|---|
| Gross Power | 275.0 hp |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 811 lb-ft |
Dimensions
| Height - Top of Cab | 149 in |
|---|---|
| Overall Width | 113 in |
| Shipping Length - non tilt | 302 in |
Boom
| Max Reach w/ Head | 395 in |
|---|
Drive System
| Tire Size - front | 600-34/700-34 |
|---|---|
| Tire Size - rear | 600-26.5/710-26.5 |
| Number of Axels | 2 |
