Ponsse
Caterpillar
554
Forwarder
33 specifications
1 / 5
Image 1 of 5
Specifications
16 data points
Operating Specifications
| Operating Weight - 6wd | 26,235 lb |
|---|---|
| Fuel Capacity | 34.4 gal |
| Hydraulic System Fluid Capacity | 34.4 gal |
Engine
| Engine Model | OM904LA |
|---|---|
| Power | 173.0 hp |
| Torque | 498 lb-ft |
Hydraulic System
| Pump Type | Load-sensing system |
|---|
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Width Over Tires | 109 in |
| Length | 348 in |
| Length of Bunk Area | 192 in |
Bunk
| Load Area | 16.35 yd³ |
|---|---|
| Load Weight - 6wd | 22,046 lb |
Crane
| Max Reach | 395 in |
|---|---|
| Gross Lift Torque | 78,181 lb-ft |
| Crane Type | K70 |
