Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 11,023 lb |
|---|---|
| Tire Size | 12.5/80-14R |
| Static Tipping Weight | 8,093 lb |
| Turning Radius | 90 in |
Engine
| Engine Model | A498BPG-16 |
|---|---|
| Displacement | 193 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 55.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 104 in |
| Wheelbase | 79 in |
| Width Over Tires | 70 in |
| Reach at Max Lift and Dump | 35 in |
| Length with Bucket on Ground | 209 in |
Transmission
| Max Speed - Forward | 13.7 mph |
|---|---|
| Max Speed - Reverse | 13.7 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 0.99 yd³ |
|---|---|
| Dump Clearance at Max Raise | 94 in |
| Bucket Width | 76 in |
