Tigercat
1075
Forwarder
22 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight - 6wd | 55,300 lb |
|---|---|
| Fuel Capacity | 70.0 gal |
| Hydraulic System Fluid Capacity | 25.0 gal |
| Alternator Supplied Amperage | 65 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 6wd | 30.5-32/30.5-32 |
Engine
| Engine Model | Cummins 6 5.9 |
|---|---|
| Displacement | 359 in³ |
| Aspiration | turbocharged |
| Power | 152.0 hp |
Hydraulic System
| Relief Valve Pressure | 3,000 psi |
|---|---|
| Flow Capacity | 43.0 gal/min |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Wheelbase | 222 in |
| Width Over Tires | 125 in |
| Length | 394 in |
| Length of Bunk Area | 180 in |
Transmission
| Max Speed | 13.0 mph |
|---|---|
| Transmission Type | Clark 32000 3-speed powershift |
| Number of Forward Gears | 3 |
Bunk
| Load Area | 14.83 yd³ |
|---|---|
| Load Weight - 6wd | 20,000 lb |
Crane
| Max Reach | 271 in |
|---|---|
| Crane Type | Cranab 650XL 360 Grapple with GV12S Rotator |
