Ranger

F614A

Forwarder

Operating Weight - 6wd
62,620 lb
Max Speed
13.0 mph
Displacement
359 in³
All forwarders
Ranger F614A Forwarder
1 / 5
Image 1 of 5
Image: garageasp.com

Specifications

24 data points

Operating Specifications

Operating Specifications specifications
Operating Weight - 6wd62,620 lb
Fuel Capacity50.0 gal
Hydraulic System Fluid Capacity25.0 gal
Alternator Supplied Amperage65 A
Operating Voltage24 V
Front/Rear Tire Size - 8wd700/50x26.5
Front/Rear Tire Size - 6wd700/55x34

Engine

Engine specifications
Engine ModelCummins 6 5.9
Displacement359 in³
Aspirationturbocharged
Power152.0 hp

Hydraulic System

Hydraulic System specifications
Relief Valve Pressure3,000 psi
Flow Capacity43.0 gal/min

Dimensions

Dimensions specifications
Ground Clearance22 in
Wheelbase222 in
Width Over Tires119 in
Length394 in
Length of Bunk Area180 in

Transmission

Transmission specifications
Max Speed13.0 mph
Transmission TypeClark 32000 3-speed powershift

Bunk

Bunk specifications
Load Area14.83 yd³
Load Weight - 6wd28,000 lb

Crane

Crane specifications
Max Reach271 in
Crane TypeCranab 650XL 360 Grapple with GV12S Rotator
