Sany

SY310

Excavator

Operating Weight
66,800 lb
Max Digging Depth
292 in
Net Power
260.2 hp
All excavators
Sany SY310 Excavator
1 / 5
Image 1 of 5
Image: m.made-in-china.com

Specifications

19 data points

Operating Specifications

Operating Specifications specifications
Operating Weight66,800 lb
Hydraulic Pump Flow Capacity140.1 gal/min

Engine

Engine specifications
Engine ModelQSB8.3
Displacement507 in³
Power Measured @2,000 rpm
Net Power260.2 hp

Dimensions

Dimensions specifications
Ground Clearance20 in
Length of Track on Ground146 in
Tail Swing Radius126 in
Width to Outside of Tracks126 in

Undercarriage

Undercarriage specifications
Max Travel Speed3.2 mph
Shoe Size24 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth292 in
Max Reach Along Ground438 in
Max Loading Height281 in
Max Vertical Wall Digging Depth256 in
Shipping Length of Unit431 in
Shipping Height of Unit128 in

Bucket

Bucket specifications
Reference Bucket Capacity1.90 yd³
