Schaffer
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 13,779 lb |
|---|---|
| Tire Size | 405x70-20 |
| Static Tipping Weight | 7,937 lb |
| Turning Radius | 69 in |
Engine
| Engine Model | BF4M2012 |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 100.5 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 97 in |
| Wheelbase | 86 in |
| Width Over Tires | 81 in |
| Reach at Max Lift and Dump | 19 in |
| Length with Bucket on Ground | 211 in |
Transmission
| Max Speed - Forward | 12.5 mph |
|---|---|
| Max Speed - Reverse | 12.5 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.50 yd³ |
|---|---|
| Dump Clearance at Max Raise | 119 in |
| Bucket Width | 88 in |
