Sumitomo

SH400-3

Excavator

Operating Weight
96,122 lb
Max Digging Depth
305 in
Net Power
320.0 hp
All excavators
Sumitomo SH400-3 Excavator
1 / 5
Image 1 of 5
Image: machinecatalogic.com

Specifications

26 data points

Operating Specifications

Operating Specifications specifications
Operating Weight96,122 lb
Fuel Capacity161.2 gal
Hydraulic System Fluid Capacity118.9 gal
Hydraulic System Relief Valve Pressure4,554 psi

Engine

Engine specifications
Engine ModelAA-6SD1X
Displacement601 in³
Power Measured @1,950 rpm
Net Power320.0 hp

Dimensions

Dimensions specifications
Ground Clearance22 in
Height - Top of Cab143 in
Length of Track on Ground159 in
Tail Swing Radius143 in
Width to Outside of Tracks132 in

Undercarriage

Undercarriage specifications
Ground Pressure12 psi
Track Gauge109 in
Max Travel Speed3.3 mph
Shoe Size24 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth305 in
Max Reach Along Ground473 in
Max Loading Height305 in
Max Vertical Wall Digging Depth259 in
Max Cutting Height439 in
Shipping Length of Unit470 in
Shipping Height of Unit143 in

Bucket

Bucket specifications
Reference Bucket Capacity2.39 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed9 rpm
