Sunward

SWE330LC

Excavator

Operating Weight
73,193 lb
Max Digging Depth
294 in
Net Power
246.7 hp
All excavators
Sunward SWE330LC Excavator
1 / 5
Image 1 of 5
Image: id.made-in-china.com

Specifications

26 data points

Operating Specifications

Operating Specifications specifications
Operating Weight73,193 lb
Fuel Capacity159.9 gal
Hydraulic Pump Flow Capacity141.6 gal/min
Hydraulic System Fluid Capacity76.7 gal
Hydraulic System Relief Valve Pressure4,699 psi

Engine

Engine specifications
Engine ModelAA-6HK1XQP
Displacement475 in³
Net Power246.7 hp
Aspirationturbocharged
Max Torque644 lb-ft

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab124 in
Tail Swing Radius134 in
Width to Outside of Tracks126 in
Removal Counterweight Clearance48 in

Undercarriage

Undercarriage specifications
Track Gauge102 in
Max Travel Speed3.0 mph
Shoe Size24 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth294 in
Max Reach Along Ground438 in
Max Loading Height299 in
Max Vertical Wall Digging Depth260 in
Max Cutting Height419 in
Shipping Length of Unit439 in
Shipping Height of Unit133 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm
