Takeuchi
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 12,677 lb |
|---|---|
| Fuel Capacity | 26.4 gal |
| Tire Size | Heavy Duty - 15-19.5 12-ply |
| Hydraulic System Fluid Capacity | 19.8 gal |
| Static Tipping Weight | 9,420 lb |
| Operating Voltage | 12 V |
| Engine Oil Fluid Capacity | 2.8 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 80 A |
Engine
| Engine Model | BF4L 2011 |
|---|---|
| Displacement | 190 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 73.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,600 rpm |
Hydraulic System
| Pump Flow Capacity | 19.8 gal/min |
|---|---|
| Raise Time | 6.0 s |
| Lower Time | 4.1 s |
| Dump Time | 1.2 s |
| Relief Valve Setting | 3,263 psi |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 103 in |
| Wheelbase | 86 in |
| Width Over Tires | 81 in |
| Reach at Max Lift and Dump | 30 in |
| Length with Bucket on Ground | 2,635 in |
| Hinge Pin - Max Height | 133 in |
Transmission
| Max Speed - Forward | 12.4 mph |
|---|---|
| Transmission Type | Hydrostatic |
Bucket
| Bucket Capacity - heaped | 1.29 yd³ |
|---|---|
| Dump Clearance at Max Raise | 1,230 in |
| Breakout Force | 15,287 lb |
| Bucket Width | 978 in |
