Tata Hitachi
EX350 LCH
- Operating Weight
- 74,957 lb
- Max Digging Depth
- 260 in
- Max Digging Depth
- 152 in
- Net Power
- 226.7 hp
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight | 74,957 lb |
|---|---|
| Fuel Capacity | 148.0 gal |
| Hydraulic Pump Flow Capacity | 137.4 gal/min |
| Hydraulic System Fluid Capacity | 84.6 gal |
| Hydraulic System Relief Valve Pressure | 4,978 psi |
| Engine Oil Capacity | 9.3 gal |
| Cooling System Fluid Capacity | 10.4 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 4.5 gal |
Engine
| Engine Model | B-65D1T |
|---|---|
| Displacement | 601 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 226.7 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,600 rpm |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 124 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 131 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 260 in |
|---|---|
| Max Reach Along Ground | 396 in |
| Max Loading Height | 263 in |
| Max Vertical Wall Digging Depth | 189 in |
| Max Cutting Height | 379 in |
Bucket
| Reference Bucket Capacity | 2.00 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.50 yd³ |
| Minimum Bucket Capacity | 1.80 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 152 in |
|---|---|
| Max Vertical Wall Digging Depth | 222 in |
| Max Cutting Height | 389 in |
| Max Loading Height | 270 in |
| Max Reach Along Ground | 408 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 292 in |
|---|---|
| Max Cutting Height | 403 in |
| Max Loading Height | 281 in |
| Max Vertical Wall Digging Depth | 256 in |
| Max Reach Along Ground | 430 in |
