Tata Hitachi
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
Tata Hitachi
ZAXIS450LCH
- Operating Weight
- 103,838 lb
- Max Digging Depth
- 229 in
- Max Digging Depth
- 246 in
- Net Power
- 315.2 hp
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight | 103,838 lb |
|---|---|
| Fuel Capacity | 171.8 gal |
| Hydraulic Pump Flow Capacity | 190.3 gal/min |
| Hydraulic System Fluid Capacity | 21.2 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 14.6 gal |
| Cooling System Fluid Capacity | 16.2 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.8 gal |
Engine
| Engine Model | AA-6WG 1TQA |
|---|---|
| Displacement | 957 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 315.2 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 940 lb-ft |
Dimensions
| Ground Clearance | 30 in |
|---|---|
| Height - Top of Cab | 133 in |
| Tail Swing Radius | 138 in |
| Width to Outside of Tracks | 138 in |
| Removal Counterweight Clearance | 54 in |
Undercarriage
| Ground Pressure | 12 psi |
|---|---|
| Track Gauge | 114 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 53 |
| Number of Carrier Rollers per Side | 3 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 229 in |
|---|---|
| Max Reach Along Ground | 402 in |
| Max Loading Height | 288 in |
| Max Vertical Wall Digging Depth | 168 in |
| Max Cutting Height | 420 in |
Bucket
| Reference Bucket Capacity | 2.50 yd³ |
|---|---|
| Maximum Bucket Capacity | 4.00 yd³ |
| Minimum Bucket Capacity | 2.50 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 246 in |
|---|---|
| Max Vertical Wall Digging Depth | 196 in |
| Max Cutting Height | 421 in |
| Max Loading Height | 289 in |
| Max Reach Along Ground | 418 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 288 in |
|---|---|
| Max Cutting Height | 404 in |
| Max Loading Height | 277 in |
| Max Vertical Wall Digging Depth | 189 in |
| Max Reach Along Ground | 442 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 306 in |
|---|---|
| Max Cutting Height | 437 in |
| Max Reach Along Ground | 466 in |
| Max Loading Height | 302 in |
| Max Vertical Wall Dig Depth | 260 in |
