Terex
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 38,581 lb |
|---|---|
| Fuel Capacity | 69.8 gal |
| Hydraulic Pump Flow Capacity | 68.7 gal/min |
| Hydraulic System Fluid Capacity | 47.6 gal |
| Hydraulic System Relief Valve Pressure | 5,221 psi |
| Engine Oil Capacity | 2.7 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | BF6M 2012C |
|---|---|
| Displacement | 370 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 150.0 hp |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 146 in |
| Tail Swing Radius | 86 in |
| Width to Outside of Tracks | 110 in |
| Removal Counterweight Clearance | 43 in |
Undercarriage
| Track Gauge | 88 in |
|---|---|
| Max Travel Speed | 3.0 mph |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 227 in |
|---|---|
| Max Cutting Height | 396 in |
Bucket
| Reference Bucket Capacity | 1.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.50 yd³ |
| Minimum Bucket Capacity | 0.90 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 248 in |
|---|---|
| Max Cutting Height | 414 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 211 in |
|---|---|
| Max Cutting Height | 313 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 230 in |
|---|---|
| Max Cutting Height | 324 in |
