Terex
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 67,241 lb |
|---|---|
| Fuel Capacity | 112.3 gal |
| Hydraulic Pump Flow Capacity | 84.6 gal/min |
| Hydraulic System Fluid Capacity | 133.5 gal |
| Hydraulic System Relief Valve Pressure | 5,512 psi |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 5.6 gal |
Engine
| Engine Model | BF6M 1013 ECP |
|---|---|
| Displacement | 436 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 231.0 hp |
| Aspiration | Turbocharging/intercooler |
Dimensions
| Height - Top of Cab | 124 in |
|---|---|
| Length of Track on Ground | 154 in |
| Tail Swing Radius | 131 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 49 in |
Undercarriage
| Track Gauge | 103 in |
|---|---|
| Max Travel Speed | 3.3 mph |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 292 in |
|---|---|
| Max Cutting Height | 504 in |
Bucket
| Reference Bucket Capacity | 2.00 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.00 yd³ |
| Minimum Bucket Capacity | 1.20 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 312 in |
|---|---|
| Max Cutting Height | 522 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 251 in |
|---|---|
| Max Cutting Height | 329 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 272 in |
|---|---|
| Max Cutting Height | 337 in |
