Terex
Volvo
L50C
Wheel Loader
43 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 32,855 lb |
|---|---|
| Fuel Capacity | 63.5 gal |
| Tire Size | 20.5-25 EM |
| Hydraulic System Fluid Capacity | 35.7 gal |
| Static Tipping Weight | 24,251 lb |
| Operating Voltage | 24 V |
| Turning Radius | 240 in |
| Rear Axle Oscillation | 24 ° |
Engine
| Engine Model | 1106C-E60 TA |
|---|---|
| Displacement | 366 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 175.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 42.3 gal/min |
|---|---|
| Relief Valve Setting | 4,500 psi |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 122 in |
| Width Over Tires | 94 in |
| Reach at Max Lift and Dump | 46 in |
| Length with Bucket on Ground | 288 in |
| Hinge Pin - Max Height | 159 in |
Transmission
| Max Speed - Forward | 24.9 mph |
|---|---|
| Max Speed - Reverse | 24.9 mph |
| Transmission Type | hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 3.51 yd³ |
|---|---|
| Dump Clearance at Max Raise | 113 in |
| Breakout Force | 26,978 lb |
| Bucket Width | 100 in |
