Terex

TXC 470LC-1

Excavator

Operating Weight
103,400 lb
Max Digging Depth
307 in
Max Digging Depth
332 in
Net Power
312.0 hp
All excavators
Terex TXC 470LC-1 Excavator
1 / 5
Image 1 of 5
Image: discount-equipment.com

Specifications

45 data points

Operating Specifications

Operating Specifications specifications
Operating Weight103,400 lb
Fuel Capacity163.8 gal
Hydraulic Pump Flow Capacity189.7 gal/min
Hydraulic System Fluid Capacity129.5 gal
Hydraulic System Relief Valve Pressure4,550 psi
Engine Oil Capacity7.4 gal
Cooling System Fluid Capacity15.4 gal
Operating Voltage24 V
Swing Drive Fluid Capacity1.1 gal

Engine

Engine specifications
Engine ModelDE12TIS
Displacement675 in³
Power Measured @2,000 rpm
Net Power312.0 hp
AspirationTurbocharged air to air intercooled
Torque Measured @1,400 rpm
Max Torque962 lb-ft

Dimensions

Dimensions specifications
Ground Clearance30 in
Height - Top of Cab132 in
Length of Track on Ground176 in
Tail Swing Radius145 in
Width to Outside of Tracks154 in
Removal Counterweight Clearance57 in

Undercarriage

Undercarriage specifications
Ground Pressure12 psi
Track Gauge131 in
Number of Track Rollers per Side9
Max Travel Speed3.2 mph
Shoe Size24 in
Number of Shoes per Side53
Number of Carrier Rollers per Side3

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth307 in
Max Reach Along Ground467 in
Max Loading Height312 in
Max Vertical Wall Digging Depth173 in
Max Cutting Height437 in
Shipping Length of Unit478 in
Shipping Height of Unit146 in

Bucket

Bucket specifications
Reference Bucket Capacity2.90 yd³
Maximum Bucket Capacity3.81 yd³
Minimum Bucket Capacity2.00 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth332 in
Max Vertical Wall Digging Depth194 in
Max Cutting Height443 in
Max Loading Height318 in
Max Reach Along Ground490 in
