Thomas
John Deere
4475
Skid Steer Loader
24 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 7,000 lb |
|---|---|
| Max Speed | 7.7 mph |
| Hydraulic System Fluid Capacity | 14.8 gal |
| Operating Voltage | 12 V |
| Operating Speed | 7.7 mph |
Engine
| Engine Model | V2203T Turbo |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 59.5 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 16.6 gal/min |
|---|---|
| Relief Valve Pressure | 2,400 psi |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 84 in |
| Wheelbase | 40 in |
| Width Over Tires | 69 in |
| Reach at Max Lift and Dump | 21 in |
| Length with Bucket | 139 in |
| Clearance at Max Lift and Dump | 110 in |
| Turning Radius from Center - inc bucket | 83 in |
| Turning Radius from Center - machine rear | 66 in |
| Length w/o Bucket | 110 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,750 lb |
| Breakout Force | 4,250 psi |
