Thomas
Yanmar
ViO25-6A
Mini Excavator
20 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 9,833 lb |
|---|---|
| Fuel Capacity | 17.0 gal |
| Hydraulic Pump Flow Capacity | 43.2 gal/min |
| Hydraulic System Relief Valve Pressure | 8,745 psi |
Engine
| Engine Model | 4LE1PA-03 |
|---|---|
| Displacement | 133 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 44.8 hp |
Dimensions
| Height - Top of Cab | 97 in |
|---|---|
| Length of Track on Ground | 76 in |
| Tail Swing Radius | 59 in |
| Width to Outside of Tracks | 73 in |
Undercarriage
| Track Gauge | 50 in |
|---|---|
| Max Travel Speed | 2.9 mph |
| Shoe Size | 16 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 162 in |
|---|---|
| Max Vertical Wall Digging Depth | 132 in |
| Max Loading Height | 166 in |
| Shipping Length of Unit | 224 in |
| Max Cutting Height | 235 in |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
