Tigercat

1045

Forwarder

Operating Weight - 8wd
35,715 lb
Max Speed
15.0 mph
All forwarders
Tigercat 1045 Forwarder
1 / 5
Image 1 of 5
Image: skidderwindows.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight - 8wd35,715 lb
Fuel Capacity55.0 gal
Hydraulic System Fluid Capacity33.9 gal
Alternator Supplied Amperage140 A
Operating Voltage24 V
Front/Rear Tire Size - 8wd600/55 x 26.5
Front/Rear Tire Size - 6wd700/55x34 / 700/50x26.5

Engine

Engine specifications
Engine Model906 Tier III
Power Measured @2,200 rpm
Power201.0 hp

Hydraulic System

Hydraulic System specifications
Pump Typevariable displacement axial piston

Dimensions

Dimensions specifications
Ground Clearance28 in
Width Over Tires104 in
Length379 in
Length of Bunk Area103 in

Transmission

Transmission specifications
Max Speed15.0 mph
Transmission TypeHydrostatic 2-speed gearbox

Bunk

Bunk specifications
Load Area17.19 yd³
Load Weight - 8wd24,250 lb

Crane

Crane specifications
Max Reach296 in
Gross Lift Torque77,449 lb-ft
Crane TypeCranab FC105 with telescopic stick
Gross Slew Torque19,100 lb-ft
