Tigercat
Caterpillar
554
Forwarder
33 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight - 8wd | 37,148 lb |
|---|---|
| Fuel Capacity | 55.0 gal |
| Hydraulic System Fluid Capacity | 33.9 gal |
| Alternator Supplied Amperage | 140 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 8wd | 710/45x26.5 |
| Front/Rear Tire Size - 6wd | 700/55x34 / 700/50x26.5 |
Engine
| Engine Model | 906 Tier III |
|---|---|
| Power Measured @ | 2,200 rpm |
| Power | 228.0 hp |
Hydraulic System
| Pump Type | variable displacement axial piston |
|---|
Dimensions
| Ground Clearance | 28 in |
|---|---|
| Width Over Tires | 118 in |
| Length | 379 in |
| Length of Bunk Area | 115 in |
Transmission
| Max Speed | 13.0 mph |
|---|---|
| Transmission Type | Hydrostatic 2-speed gearbox |
Bunk
| Load Area | 21.04 yd³ |
|---|---|
| Load Weight - 8wd | 30,850 lb |
Crane
| Max Reach | 296 in |
|---|---|
| Gross Lift Torque | 77,449 lb-ft |
| Crane Type | Cranab FC 105 with telescopic stick |
| Gross Slew Torque | 19,100 lb-ft |
