Valmet
Caterpillar
554
Forwarder
33 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight - 8wd | 33,950 lb |
|---|---|
| Operating Weight - 6wd | 30,650 lb |
| Fuel Capacity | 42.0 gal |
| Hydraulic System Fluid Capacity | 26.5 gal |
| Alternator Supplied Amperage | 100 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 8wd | front & rear :600/ 55x26.5 700/50x26.5 710/45x26.5 |
| Front/Rear Tire Size - 6wd | 600/ 65x34 700/ 55x34 710/ 55x34 / rear :600/55x26.5 700/50x26.5 710/45x26.5 |
Engine
| Engine Model | 66 CTA Commonrail.Tier 3 |
|---|---|
| Power | 168.0 hp |
| Torque | 520 lb-ft |
Hydraulic System
| Pump Type | Variable piston Pump |
|---|---|
| Relief Valve Pressure | 3,400 psi |
| Flow Capacity | 76.0 gal/min |
Dimensions
| Ground Clearance | 28 in |
|---|---|
| Wheelbase | 66 in |
| Width Over Tires | 24 in |
| Length | 366 in |
| Length of Bunk Area | 196 in |
| Height to Top of crane | 150 in |
Transmission
| Max Speed | 15.0 mph |
|---|---|
| Transmission Type | Hydrostatic |
Bunk
| Load Area | 2.96 yd³ |
|---|---|
| Load Weight - 8wd | 26,460 lb |
| Load Weight - 6wd | 26,460 lb |
Crane
| Max Reach | 307 in |
|---|---|
| Gross Lift Torque | 78,299 lb-ft |
| Crane Type | CRF 8.1 |
| Gross Slew Torque | 6,460 lb-ft |
